Sinotruk Howo 6x4 Water Truck - Special Trucks

Introduction

The Sinotruk Howo 6×4 Water Truck is an efficient vehicle designed for urban and rural water transportation. With a 6×4 drive, it has the power and stability to maneuver smoothly in all kinds of complex road conditions.The Sinotruk Howo 6×4 Water Truck has a large water tank capacity, typically up to 10 cubic meters or more, to meet large-scale irrigation, firefighting and cleaning needs.

Whether it is on the road in the city or in the field in the countryside, the Sinotruk Howo 6×4 Water Truck works excellently and is ideal for all types of water transportation. Its reliable performance and economical operating costs make it the first choice for many users.

Sinotruk Howo 6×4 Water Truck Specifications

Sinotruk Howo 6×4 Water Truck
Chassis Model	ZZ1257N4347D1B
Driving Type	LHD (RHD is optional)
Cabin	HW76 cab, with one sleeper, two seats, 2-arm windscreen wiper system with three speeds, damped adjustable driver’s seat, with heating and ventilating system, exterior sun visor, safety belts, adjustable steering wheel, air horn, air conditioner, with transverse stabilizer,with 4-point support fully floating suspension + shock absorber.
Engine	Make: WICHAI Diesel 4-stroke direct injection diesel engine Engine model: WP12.400E201, Euro II, 400 HP 6-cylinder in-line with water cooling, turbo-charging and intercooling Displacement: 11.596 L
Transmission	HW19710, 10F & 2R Ratio: 14.28, 10.62, 7.87, 5.88, 4.38, 3.27, 2.43, 1.80, 1.34, 1.00, 13.91(R1), 3.18(R2)
Steering	ZF power steering, model ZF8118, hydraulic steering with power assistance
Front Axle	VGD95, 1×9000 KGS Steering with double T-cross section beam
Rear Axle	HC16, 2×16000 KGS Pressed axle housing, central single reduction with hub reduction and with differential locks between wheels and axles. Ratio:4.42
Propeller Shaft	Double universal joint propeller shaft with gear-shaped coupling flange
Chassis	Frame: U-profile parallel ladder frame with section of 300x80x8mm, and reinforced subframe all cold riveted cross members Front suspension:10 semi-elliptic leaf spring, hydraulic telescopic double-action shock absorbers and stabilizer Rear suspension:12 leaf semi-elliptic springs, bogie spring and stabilizer
Brake	Service brake: dual circuit compressed air brake Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels Auxiliary brake: engine exhaust brake
Electrics	Operating voltage: 24 V, negative grounded Starter: 24 V, 5.4 Kw Alternator: 3-phase, 28 V, 1500 W Batteries: 2 x 12 V, 165 Ah Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light
Tyres	*12.00R20, Radial tires* with one spare tire
Fuel Tank	400L
Tank Body	Capacity: 20 Cubic Meters, 20,000 Liters Front and Rear sprinkling system High Press Water Jet. *Turning Lights*
Overall Dimension	980025003350mm

Field application

HOWO Engineering Expert

The diverse range of chassis options can accommodate a variety of vehicle modification needs, while the multiple powertrain choices are applicable to diverse specialized vehicle use cases. Our in-house modification company and world-class modification companies are available to serve your customization needs.

All-Around Vision, Everything in Sight

Featuring wide-view design, four-way monitoring system (optional), and observation window (optional), the driver is accessible to comprehensive visual information about the surrounding environment and traffic dynamics of the vehicle, thus making accurate assessments, and safely responding to various situations.

MC Series Engine

Safe Driving Cabin

Air Suspension Seat
