Trailer Size:12500*2500*1500
Color:Customizable
Global service – provide 24-hour after-sales support, fast delivery, and assist in obtaining transportation permits (such as overload permits).
1. 40-foot extra-long flatbed – provides more loading space, suitable for extra-long and extra-wide goods (such as pipes and prefabricated parts).
2. Heavy-duty three-axle design – 40ft tri axle flatbed semi trailer meets international standards such as DOT/GB to ensure legal and compliant use on the road.
3. Customizable options – optional gooseneck/flatbed, additional side rails, anti-slip surface, hydraulic tailgate, etc.
4. High-quality tires & brake system – 40ft flatbed trailer equipped with tubeless tires/wire tires, with ABS/EBS braking system to improve safety.
5. Convenient loading and unloading design – low-profile or removable side rails for easy forklift and crane operations.

| SINOTRUK 40FT TRI-AXLE FLATBED SEMI TRAILER | ||
| Trailer Body | Trailer Size | 12500*2500*1500 |
| Capacity | 40,000 kg | |
| Longitudinal Beam | 520 mm | |
| I-beam | Q345 14/6/16 mm | |
| Floor | 2.75mm Patterned Board | |
| Side frame | 160mm Channel Steel | |
| Lock | 12 sets | |
| Runing Gear | Axle | JMCG 13T*3 |
| The Suspension System | Mechanical suspension | |
| Leaf Spring | 10*13 | |
| Tire | 12R22.5 *13 (TRIANGLE) | |
| Rim | China Brand 9.0-22.5 *13 | |
| LandingGear | JMCG 30TON | |
| Kingpin | JOST 2″ bolton type | |
| Brake system | 2 lines air brake with air tank | |
| Relay valve | WABCO | |
| ABS | WITHOU | |
| Chamber | T30/30 on rear two axle;T30 on first one axle | |
| Tool Box | 1000 mm 1 Set | |
| Oil Tank | 1200 L 1 Set Material Q235 | |
| Spare Tire Rack | 2set Standard Type | |
| Lights | 24V, LED | |
| Color | Powder coating process (customizable) | |
| Trailer weight | About 7000 Kg | |
