Howo TX 4X2 Tractor Truck- SINOTRUK

Introduction

Howo TX Tractor Truck comes from a prestigious family with advanced technology from MAN, and its prototypes have won numerous European Truck of the Year awards. From design concept, product design, production and assembly process, production consistency management, test verification to product release, the TX TX adopts German standards.

Howo TX Tractor Truck has the active and passive safety of the world’s top heavy trucks. Cab crash indexes can meet the Swedish standard, and the steering column can be deformed and absorbed in a collision; EVB (engine exhaust valve brake) is equipped as standard.

Vehicle model	Howo TX 4X2 Tractor Truck
MOTEUR	Model: MC07.28-30, Euro Ill emission standard, German technology MAN 4-stroke common rail injection diesel engine 6-cylinder in-line with water-cooling, supercharging and intermediate cooling Maximum power: 280 hp (206 kW) at 2300 rpm Maximum toll: 1100 Nm at 1200 – 1800 rpm/minAir purifier Oil fan silicone oil fan
CARTON	Dry-spring clutch, single-disc, diameter 430 mm, hydraulically controlled with pneumatic assistance
SPEED CARTON	9 front-on gear ratios and 1 reverse gear ratio, with synchronizer, with overgear
SUPPLY BEFORE	Rigid axle shoe with drum, Capacity 6000kg, German technology MAN
REAR ESSIUE	Double-reduced sun axle casing with differential locking between wheels and axles, Capacity 13000kg, German technology MAN
CHASSIS	Frame: U-sectional scale frame with section (height, width, thickness) of 250-80-(7-4) mm Front suspension: 11-layer semi-elliched blade springs with double-acting telescopic hydraulic dampers and stabilizer Rear suspension: semi-elliptical blade springs 9-8 layers Fuel tank capacity (L): 400L, fuel tank
PILOTING	BOSCH-marked power steering, hydraulic steering with electric assistance, adjustable column inclination and height with locking
Freins	Dual-circuit compressed air brake Parking brake: spring energy, compressed air operating on the rear wheels WABCO ABS
WHEELS and PNEUS	Tyres:12R22.5 without inner tube with emergency tyre
CABINE	TX-M hydraulically tilable 70 degrees forward, two-arm wiper with three speeds, air conditioning system, air conditioning, air conditioning, air conditioning, air conditioning, longitudinal adjustment, static co-pilot seat back and height height, laminated windshield with integrated sunscreen radial antenna for windscreens, window liftersco-pilot, ashtray in the middle of the dashboard for driver and co-pilot, Multifunction steering wheel, Radio-video with loudspeakers at the door, fine dust filter and pollen for the cab, sun visor in front of windscreen, wide-angle mirror, left and right, the display in the “French” language.
DIMENSION IN MM	Wheelbase (mm)	6200
	Total length (mm)	10400
	Overall width (mm)	2550
	Total height (mm)	3100
KG WEIGHT	Unladen weight (kg)	5600
	Total permissible mass (kg)	19000

Field application

High Reliability

Introduce the original German MAN TG series vehicle technology, the same product design and the same production assembly technology, completely adopt the German standard in the production conformity management, testing & validation and the product release, and synchronize the parts purchasing system with MAN company, allof which are the strong guarantee of the vehicle high reliability.

Engine

DERIVING FROM MAN AND IMPROVED IN CHINA MC11 engine has a very wide area of low oil consumption and large torque, The minimum specific fuel consumption is only 186 g/kw / h; The internal mileage of the engine oil change can reach 80000 kilometers.Its B10 life could reach 1.5 million kilometers.
