Home Truck Dump Truck

Howo NX 8X4 Dump Truck

ModelZZ3317V386JB1
Engine380/400
Fuel Tank (L)300
Full loaded mass 31000kg
Rear AxleMCX16/5.72
Howo NX 8X4 Dump Truck
product img
product img

Introduction

HOWO NX  8×4 Dump Truck
Weight Parameter Curb mass (kg) 15830
Full loaded mass (kg) 31000
Dimension Parameter External Size (L*W*H) mm 10745*2496*3668
Wheel Base(mm) 1800+3800+1350
Performance Parameter Max.Speed(km/h) 90
Economic Speed (km/h) 65~80
Max.Grade Ability (%) 34
Engine Horsepower 380/400
Type water-cooled, turbo-charged & inter-cooled, direct injection
Rear Axle Type MCX16
Rear Axle Ratio 5.72
Carriage Carriage Internal Dimensions (mm) 6200~8800* 2300*1500
Cubage (m³) 21~30
Steel thickness of Carriage (mm) Floor:8mm/ Side:4mm (Mn16)
Fuel Tank (L) 300
Tire 12.00R20 /295/ 80R22.5

Field application

High Reliability
High Reliability
Introduce the original German MAN TG series vehicle technology, the same product design and the same production assembly technology, completely adopt the German standard in the production conformity management, testing & validation and the product release, and synchronize the parts purchasing system with MAN company, allof which are the strong guarantee of the vehicle high reliability.
Engine
Engine
DERIVING FROM MAN AND IMPROVED IN CHINA MC11 engine has a very wide area of low oil consumption and large torque, The minimum specific fuel consumption is only 186 g/kw / h; The internal mileage of the engine oil change can reach 80000 kilometers.Its B10 life could reach 1.5 million kilometers.
